SatLink WS6908 Professional Satellite Finder Meter DVB-S

WS-6908 Digital LCD Professional Satellite Finder Meter Plus Download And Watch All FTA Digital Satellite Channels On Colour LCD Screen

* View the actual channel on the screen of the meter.
* Quickly and accurately align the satellite dish and instantly check the stability of the channels right on the screen of the meter.
* Transponders, Frequency, Symbol Rate, Polarity, and other settings can be modified by the user.
* There is never a need to send your meter in for a upgrade.
* The meter never needs to be returned for re-calibration due to the unique calibration system built in to the meter. Each time the meter boots up it automatically calibrates for optimum performance so you can align each install with confidence.

SPECIAL FEATURES INCLUDE:

* It is a battery powered hand held Satellite alignment meter demodulating DVB-S Signal. It's very convenient for installer to catch quick and accurate Alignment for Antenna to the best position.
* It's with microprocessor controller, reliable and stable performance. When it's turned on, channel picture, Signal Strength and Signal Quality will be showed on LCD Screen after you set up your local DVB-S Parameter. Also, it enables you to select big menu window for data figure which is helpful for alignment.
* It shows Azimuth and Elevation, CBER/VBER, S/N, Signal Strength and signal lock sound
* It detects very faint signal, and supports antenna power OFF/13V/18V selectable.
* It's with auto-protection for LNB short-circuit. It includes both AV IN and AV OUT for Camera, LCD...etc
* It's used with 12V Power Adaptor when you need to use external power.
* It includes high capacity Lithium Battery 8.4V3000mAh which works for more than 4 hours after it's fully charged.

* View All The Actual FTA Satellite Channels On The Meters Screen.
* Auto Re-Calibration Due To The Unique Calibration System Built in to the Meter.
* Automatically Calculates Dish Angles And Settings Based On Your Longitude And Latitude.
* Calculates Your Dish Angles and Alignment Settings so you can quickly and accurately align the satellite dish and you can instantly check the stability of the channel right on the screen of the meter.
* Each time the meter boots up it automatically calibrates for optimum performance so you can align each install with confidence.
* All Transponders, Frequency, Symbol Rate, Polarity, and other settings can be modified by the user.
* View All FTA Satellite Channels On Screen With Sound.

TECHNICAL SPECS:

* System Capabilities Fully DVB-S Compliant Yes
* LNB input Connector F type, Female
* Frequency Range 950MHz-2150MHz
* Signal Level -65dBm~-25dBm
* LNB Power 13/18V,Max350mA
* LNB Switch Control 22KHz
* DiSEqC Ver 1.0/ 1.2
* Demodulator Front end QPSK
* Demodulation Range 2Mbps~45Mbps
* SCPC and MCPC Capable Yes
* System Resources Processor 32bit processor (133MHz)
* FLASH 8Mbyte
* SDRAM 4*16Mbyte
* Video Decoder MPEG 2 MP@ML
* Data Rate Max15M bits/s
* Resolution 720*576,720*480
* Video format PAL/NTSC/SECAM
* Audio MPEG
* MPEG-1&2 Type Single
* Sampling Rate 32,44.1 & 48KHz
* Data Transfer Connector USB
* Power Supply LI-ION battery 3000 mAH/8.4V Max
* Power Adaptor In AC 100-220 Out DC 12V
* Physical characteristics Size 9.5x15.5x4.5 (cm)
* Net Weight 0.5KG

Items Included:

* Sat-Link Meter WS6908 LI-ION battery 3000 mAH/8.4V Max
* Neck Strap
* Carrying case
* 12VDC Power Charger
* Two Pin 12VAC Mains Power Charger
