SatLink WS6936 DVB-S & T Combo Satellite & Aerial Meter With Spectrum

SatLink WS6936 DVB-S & DVB-T Combo Satellite & Aerial Meter With Spectrum

Specifications:

*4.3 Inch High Definition TFT LCD Screen
*Both AV IN And AV Out
*8.4V/3000mAh Lion Battery Included
*Max Operating Time:4 hours
*12V/1.5A DC Adapter
*Sound and Light Alarm for Locking Signal
*USB Port For Software Upgrades
*Speaker Integrated


DVB-S
*Input Frequency 950~2150MHz
*Input Level -65~ -25dBm
*Input Impedance 75O
*Constellation analyzer
*Spectrum analyzer
*Support DISEQC 1.0,1.1,1.2 and 22khz Tone
*Measurement Type: signal strength,quality; BER; S/N;PWR
*Search Mode: Auto,Blind,Manual
*LNB Power Supply:18/13V(IMax 400mA)

DVB-T
*Frequency Range: 46MHz-862MHz
*Level range:40dBµV-110dBµV
*Input Impedance:75O
*Multichannel check
*Demodulation:QPSK,16QAM,64QAM
*Measurement Type: signal strength,quality; MER; S/N;PWR
*Search Mode: Auto,Manual
*ANT Power Supply:5V/12V/24V
