SatLink WS6922 DVB-S2 MPEG4 HD Satellite Meter

SatLink WS6922 DVB-S2 MPEG4 HD Satellite Meter

SatLink WS6922 DVB-S2 MPEG4 HD Satellite Meter


Professional HD Satellite Meter:


PLAY'S LIVE FTA SD & HD SATELLITE TV CHANNELS


DIGITAL SATELLITE FINDER WITH HD PICTURE


Product Includes:


1x WS-6922 HD Satellite Finder
1x Yellow Protective Case
1x Car Charger Cable
1x AV Cable
1x Power Adapter
1x Connector
1x Black Carrying Case
1x Strap
1x Software CD

Features:


It can receive DVB-S and DVB-S2 signal for HD TV program watching.
3.5" LCD color display, bigger menu window.
WS 6922 uses microprocessor controller with reliable and stable performance.
Channel picture, signal strength and signal quality can be showed on LCD Screen.
It shows Azimuth and Elevation, CBER/VBER, S/N, signal strength and signal lock sound alarm.
It can detect very weak signal and provide antenna power(OFF/13V/18V).
Supports both AV IN and AV OUT for camera, LCD, etc.
Designed with key backlighting and flashlight.
It can connect to external USB device and play the music in MP3 format. (The U-disk in the picture is not included in the package)
Matched with a high quality protective case.
Built-in 3000mAH large capacity Li-ion battery.
Support language: English, French, Turkish, Arabic.
English user manual is included in the CD disk.

Satlink WS-6922 HD is an easy Satfinder for DVB-S + S2 with HD TV-Picture
Satlink WS-6922 HD has an integrated colour TFT LC Display with 3,5" / 8,9cm
Satlink WS-6922 HD is excellent for aliging Satellite Dishes
Satlink WS-6922 HD can display Digital and HD TV-Programs for testing
Satlink WS-6922 HD can connect to a TV and use as a normal satellite receiver (AV-Output)
Satlink WS-6922 HD can connect with a TV-Camera to use the Meter as a Monitor (AV-Input)

AV IN- & OUTPUT
Satlink WS-6922 DVB-S can be connected as a standard receiver to a TV. In addition, the device has an AV input. At this, other media players or AV surveillance cameras to be connected!

SPECIAL FEATURES INCLUDE:


* It can receive DVB-S and DVB-S2 signal for HD TV program watching.
* 3.5" LCD color display, bigger menu window.
* WS 6922 uses microprocessor controller with reliable and stable performance.
* Channel picture, signal strength and signal quality can be showed on LCD Screen.
* It shows Azimuth and Elevation, CBER/VBER, S/N, signal strength and signal lock sound alarm.
* It can detect very weak signal and provide antenna power(OFF/13V/18V).
* Supports both AV IN and AV OUT for camera, LCD, etc.
* Designed with key backlighting and flashlight.
* It can connect to external USB device and play the music in MP3 format. (The U-disk in the picture is not included in the package)
* Matched with a high quality protective case.
* Built-in 3000mAH large capacity Li-ion battery.
* Support language: English, French, Turkish, Arabic.
* English user manual is included in the CD disk.

FEATURES ALSO INCLUDE:


* Colour TFT LC Display with 3,5" / 8,9cm
* Keypad with Lighting
* Flashlight Function (built-in LED Lamp on the Rear)
* Frequency range: 950 - 2150 MHz (DVB-S + S2)
* Built-in speaker
* Angle calculation of Azimuth, Alevation and LNB Tilt (after entering the Coordination own Data)
* Sound warning prompt locking Satellite
* Display the Signal Strength in Percent and as a Bar
* Display of BER
* Display of C/N
* Display of Signal Range in dBµV
* DiSEqC Motor Control
* DiSEqC Control for Multi-Switch and simple DiSEqC Switches
* Automatc Channel Scan TV + Radio
* Receive and Play of DVB-S+S2 HD FTA TV Programs in Picture and Tone
* Receive and Play of DVB-S FTA Radio Programs in Ton
* Switching the Screen Size 4:4 / 16:9
* AV in and AV out function
* Software Upgradeable via USB flash Stick
* Storage and recovery of their own system settings using a USB flash Stick
* Lithium-ion 3000mA Power Battery
